Aeonic Brick Surface 1×5

  • Gallery Image

Aeonic Brick Surface 1×5

Interior Spaces

The Aeonic Brick Surface 1×5 delivers powerful, uniform illumination in a surface-mounted configuration. With five diamond-shaped reflectors, it ensures linear consistency and optical precision for expansive interior zones, offering easy mounting on solid ceilings or exposed structural grids

Enquire Now

Specifications

Product Image
Wattage
10W
Lumen
905 lm - 955 lm
Beam Angle
15°/ 24°/ 38°/ 60°
UGR
<19
IP rating
IP20
check icon
Extended Surface-Mount Profile
Ideal for large-area illumination without recess requirements.
check icon
Diamond Reflector Technology
Ensures controlled beam angles and glare-free brightness.
check icon
Integrated Driver Assembly
Facilitates streamlined connection and thermal management.
check icon
Comprehensive Dimming Compatibility
Available with Non-Dimmable, Analog, Triac, DALI, DALI Tunable, and RF Tunable dimming.

Product Details

Model Model Name Model No Size Wattage Lumens CCT CRI Beam Angle IP Rating Accessories Dimming Option Specssheet 2D 3D Installation Manual
product-img Aeonic Brick 1x5-Surface 1268 W137 x H65 mm 10 955 4000 92 15 IP20 NA Non Dim/Triac Dim/Analog Dim/DALI Dim/Dali Tunable/RF Tunable Download Download Download Download
product-img Aeonic Brick 1x5-Surface 1268 W137 x H65 mm 10 955 4000 92 24 IP20 NA Non Dim/Triac Dim/Analog Dim/DALI Dim/Dali Tunable/RF Tunable Download Download Download Download
product-img Aeonic Brick 1x5-Surface 1268 W137 x H65 mm 10 955 4000 92 38 IP20 NA Non Dim/Triac Dim/Analog Dim/DALI Dim/Dali Tunable/RF Tunable Download Download Download Download
product-img Aeonic Brick 1x5-Surface 1268 W137 x H65 mm 10 955 4000 92 60 IP20 NA Non Dim/Triac Dim/Analog Dim/DALI Dim/Dali Tunable/RF Tunable Download Download Download Download
product-img Aeonic Brick 1x5-Surface 1268 W137 x H65 mm 10 930 3000 92 15 IP20 NA Non Dim/Triac Dim/Analog Dim/DALI Dim/Dali Tunable/RF Tunable Download Download Download Download
product-img Aeonic Brick 1x5-Surface 1268 W137 x H65 mm 10 930 3000 92 24 IP20 NA Non Dim/Triac Dim/Analog Dim/DALI Dim/Dali Tunable/RF Tunable Download Download Download Download
product-img Aeonic Brick 1x5-Surface 1268 W137 x H65 mm 10 930 3000 92 38 IP20 NA Non Dim/Triac Dim/Analog Dim/DALI Dim/Dali Tunable/RF Tunable Download Download Download Download
product-img Aeonic Brick 1x5-Surface 1268 W137 x H65 mm 10 930 3000 92 60 IP20 NA Non Dim/Triac Dim/Analog Dim/DALI Dim/Dali Tunable/RF Tunable Download Download Download Download
product-img Aeonic Brick 1x5-Surface 1268 W137 x H65 mm 10 905 2700 92 15 IP20 NA Non Dim/Triac Dim/Analog Dim/DALI Dim/Dali Tunable/RF Tunable Download Download Download Download
product-img Aeonic Brick 1x5-Surface 1268 W137 x H65 mm 10 905 2700 92 24 IP20 NA Non Dim/Triac Dim/Analog Dim/DALI Dim/Dali Tunable/RF Tunable Download Download Download Download
product-img Aeonic Brick 1x5-Surface 1268 W137 x H65 mm 10 905 2700 92 38 IP20 NA Non Dim/Triac Dim/Analog Dim/DALI Dim/Dali Tunable/RF Tunable Download Download Download Download
product-img Aeonic Brick 1x5-Surface 1268 W137 x H65 mm 10 905 2700 92 60 IP20 NA Non Dim/Triac Dim/Analog Dim/DALI Dim/Dali Tunable/RF Tunable Download Download Download Download
