Deep-Recessed Design
Delivers glare-free, focused light.
Allura Fix brings clarity and control to architectural lighting. With its deep-set light source and multiple reflector finishes, this fixture offers pure downward illumination with superior glare reduction. Designed for designers who appreciate clean aesthetics and consistent performance, it’s ideal for accent, task, or ambient applications in modern interiors.
| Model | Model Name | Model No | Size | Wattage | Lumens | CCT | CRI | Beam Angle | IP Rating | Accessories | Dimming Option | Specssheet | 2D | 3D | Installation Manual |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Allura Fix | 1015 | Dia 85 x H 106mm | 15 | 1400 | 4000 | 95 | 60 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1015 | Dia 85 x H 106mm | 15 | 1400 | 4000 | 95 | 38 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1015 | Dia 85 x H 106mm | 15 | 1400 | 4000 | 95 | 24 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1015 | Dia 85 x H 106mm | 15 | 1400 | 4000 | 95 | 15 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1015 | Dia 85 x H 106mm | 15 | 1400 | 4000 | 95 | 10 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1015 | Dia 85 x H 106mm | 15 | 1355 | 3000 | 95 | 60 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1015 | Dia 85 x H 106mm | 15 | 1355 | 3000 | 95 | 38 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1015 | Dia 85 x H 106mm | 15 | 1355 | 3000 | 95 | 24 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1015 | Dia 85 x H 106mm | 15 | 1355 | 3000 | 95 | 15 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1015 | Dia 85 x H 106mm | 15 | 1355 | 3000 | 95 | 10 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1015 | Dia 85 x H 106mm | 15 | 1320 | 2700 | 95 | 60 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1015 | Dia 85 x H 106mm | 15 | 1320 | 2700 | 95 | 38 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1015 | Dia 85 x H 106mm | 15 | 1320 | 2700 | 95 | 24 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1015 | Dia 85 x H 106mm | 15 | 1320 | 2700 | 95 | 15 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1015 | Dia 85 x H 106mm | 15 | 1320 | 2700 | 95 | 10 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1014 | Dia 85 x H 90mm | 10 | 930 | 4000 | 95 | 60 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1014 | Dia 85 x H 90mm | 10 | 930 | 4000 | 95 | 38 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1014 | Dia 85 x H 90mm | 10 | 930 | 4000 | 95 | 24 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1014 | Dia 85 x H 90mm | 10 | 930 | 4000 | 95 | 15 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1014 | Dia 85 x H 90mm | 10 | 930 | 4000 | 95 | 10 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1014 | Dia 85 x H 90mm | 10 | 900 | 3000 | 95 | 60 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1014 | Dia 85 x H 90mm | 10 | 900 | 3000 | 95 | 38 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1014 | Dia 85 x H 90mm | 10 | 900 | 3000 | 95 | 24 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1014 | Dia 85 x H 90mm | 10 | 900 | 3000 | 95 | 15 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1014 | Dia 85 x H 90mm | 10 | 900 | 2700 | 95 | 10 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1014 | Dia 85 x H 90mm | 10 | 880 | 2700 | 95 | 60 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1014 | Dia 85 x H 90mm | 10 | 880 | 2700 | 95 | 38 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1014 | Dia 85 x H 90mm | 10 | 880 | 2700 | 95 | 24 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1014 | Dia 85 x H 90mm | 10 | 880 | 2700 | 95 | 15 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1014 | Dia 85 x H 90mm | 10 | 880 | 2700 | 95 | 10 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 10 | 930 | 4000 | 95 | 38 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 10 | 930 | 4000 | 95 | 24 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 10 | 930 | 4000 | 95 | 15 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 10 | 900 | 3000 | 95 | 38 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 10 | 900 | 3000 | 95 | 24 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 10 | 900 | 3000 | 95 | 15 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 10 | 880 | 2700 | 95 | 38 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 10 | 880 | 2700 | 95 | 24 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 10 | 880 | 2700 | 95 | 15 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 7 | 645 | 4000 | 95 | 38 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 7 | 645 | 4000 | 95 | 24 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 7 | 645 | 4000 | 95 | 15 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 7 | 625 | 3000 | 95 | 38 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 7 | 625 | 3000 | 95 | 24 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 7 | 625 | 3000 | 95 | 15 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 7 | 610 | 2700 | 95 | 38 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 7 | 610 | 2700 | 95 | 24 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
|
|
Allura Fix | 1013 | Dia 70 x H 82mm | 7 | 610 | 2700 | 95 | 15 | IP44 | Diffused Lens/Softening Lens/Honeycomb | Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tuneable/RF Tuneable | Download | Download | Download | Download |
