Multi-Point Precision
Multiple focused LED sources (a "grid") create a sharp, uniform line of accent light ideal for retail displays and art walls
Invi Grid Modules (S and M) provide a highly efficient and aesthetically striking solution for multi-point accent and display lighting within the magnetic track system. By combining multiple focused LED sources into a single linear module, the Grid creates a sharp, powerful, and uniform line of light, ideal for illuminating long display cases, gallery walls, or architectural details. With a high Type CRI 92, low glare (UGR <19), and the flexibility of magnetic attachment, the Grid modules deliver professional-grade precision in a minimalist package.
| Model | Model Name | Model No | Size | Wattage | Lumens | CCT | CRI | Beam Angle | IP Rating | Accessories | Dimming Option | Specssheet | 2D | 3D | Installation Manual |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
Joule Invi Grid | 2231 | Width 10mm x Length 263mm | 5 | 424 | 3000 | 92 | 24 | IP20 | NA | Non Dim | Download | Download | Download | Download |
|
|
Joule Invi Grid | 2231 | Width 10mm x Length 263mm | 5 | 443 | 4000 | 92 | 24 | IP20 | NA | Non Dim | Download | Download | Download | Download |
|
|
Joule Invi Grid | 2231 | Width 10mm x Length 263mm | 5 | 416 | 2700 | 92 | 24 | IP20 | NA | Non Dim | Download | Download | Download | Download |
|
|
Joule Invi Grid | 2232 | Width 10mm x Length 358mm | 7 | 622 | 4000 | 92 | 24 | IP20 | NA | Non Dim | Download | Download | Download | Download |
|
|
Joule Invi Grid | 2232 | Width 10mm x Length 358mm | 7 | 596 | 3000 | 92 | 24 | IP20 | NA | Non Dim | Download | Download | Download | Download |
|
|
Joule Invi Grid | 2232 | Width 10mm x Length 358mm | 7 | 582 | 2700 | 92 | 24 | IP20 | NA | Non Dim | Download | Download | Download | Download |
|
|
Joule Invi Grid | 2233 | Width 10mm x Length 645mm | 15 | 1277 | 3000 | 92 | 24 | IP20 | NA | Non Dim | Download | Download | Download | Download |
|
|
Joule Invi Grid | 2233 | Width 10mm x Length 645mm | 15 | 1334 | 4000 | 92 | 24 | IP20 | NA | Non Dim | Download | Download | Download | Download |
|
|
Joule Invi Grid | 2233 | Width 10mm x Length 645mm | 15 | 1247 | 2700 | 92 | 24 | IP20 | NA | Non Dim | Download | Download | Download | Download |
