Tenace Quadran

Interior Spaces

The Tenace Quadran - Square models (Trim/Trimless) are the premium solution for adjustable geometric accent lighting. These fixtures feature a clean square trim that houses a powerful Array LED (Type CRI 95) and a sophisticated gimbal system. This system allows for both 360° rotation and high-angle tilt, giving designers complete freedom to aim the beam precisely.

Enquire Now

Specifications

Product Image
Wattage
5W - 30W
Lumen
425 lm - 2745 lm
Beam Angle
15° / 24° / 38° /60°
UGR
<14
IP Rating
IP65
check icon
Clean Square Geometry
Offers a distinct square form factor that provides a modern, clean, and geometric alternative to round fixtures, perfectly aligning with orthogonal architectural lines.
check icon
Trim/Trimless Felxibility
Available with a trim for a clean finish/chromed edge or a trimless option for seamless integration into the ceiling.
check icon
Maximum Visual Comfort
Achieves a best-in-class UGR (Unified Glare Rating) of less than 16 due to the deep-recessed light engine, guaranteeing a completely stress-free lighting environment.
check icon
IP65 Option
4. As part of our premium downlight range, Tenace Square is also available in an IP65 option for lighting in weather affected areas.

Product Details

Model Model Name Model No Size Wattage Lumens CCT CRI Beam Angle IP Rating Accessories Dimming Option Specssheet 2D 3D Installation Manual
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 10 915 4000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 10 915 4000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 10 915 4000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 10 915 4000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 10 890 3000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 10 890 3000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 10 890 3000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 10 890 3000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 10 865 2700 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 10 865 2700 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 10 865 2700 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 10 865 2700 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 5 450 4000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 5 450 4000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 5 450 4000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 5 450 4000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 5 435 3000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 5 435 3000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 5 435 3000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 5 435 3000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 5 425 2700 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 5 425 2700 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 5 425 2700 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1117 52L x 52W x 96H 5 425 2700 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 10 1830 4000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 10 1830 4000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 10 1830 4000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 10 1830 4000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 10 1780 3000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 10 1780 3000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 10 1780 3000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 10 1780 3000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 10 1730 2700 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 10 1730 2700 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 10 1730 2700 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 10 1730 2700 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 12 1100 4000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 12 1100 4000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 12 1100 4000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 12 1100 4000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 12 1070 3000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 12 1070 3000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 12 1070 3000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 12 1070 3000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 12 1040 2700 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 12 1040 2700 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 12 1040 2700 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1119 74L x 74W x 130H 12 1040 2700 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 30 2745 4000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 30 2745 4000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 30 2745 4000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 30 2745 4000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 30 2670 3000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 30 2670 3000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 30 2670 3000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 30 2670 3000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 30 2595 2700 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 30 2595 2700 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 30 2595 2700 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 30 2595 2700 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 25 2285 4000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 25 2285 4000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 25 2285 4000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 25 2285 4000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 25 2225 3000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 25 2225 3000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 25 2225 3000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 25 2225 3000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 25 2160 2700 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 25 2160 2700 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 25 2160 2700 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square Trimless 1121 94L x 194W x 165H 25 2160 2700 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 10 915 4000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 10 915 4000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 10 915 4000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 10 915 4000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 10 890 3000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 10 890 3000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 10 890 3000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 10 890 3000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 10 865 2700 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 10 865 2700 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 10 865 2700 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 10 865 2700 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 5 450 4000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 5 450 4000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 5 450 4000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 5 450 4000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 5 435 3000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 5 435 3000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 5 435 3000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 5 435 3000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 5 425 2700 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 5 425 2700 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 5 425 2700 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1116 64L x 64W x 96H 5 425 2700 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 20 1830 4000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 20 1830 4000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 20 1830 4000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 20 1830 4000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 20 1780 3000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 20 1780 3000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 20 1780 3000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 20 1780 3000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 20 1730 2700 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 20 1730 2700 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 20 1730 2700 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 20 1730 2700 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 12 1100 4000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 12 1100 4000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 12 1100 4000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 12 1100 4000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 12 1070 3000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 12 1070 3000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 12 1070 3000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 12 1070 3000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 12 1040 2700 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 12 1040 2700 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 12 1040 2700 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1118 85L x 85W x 130H 12 1040 2700 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 30 2745 4000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 30 2745 4000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 30 2745 4000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 30 2745 4000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 30 2670 3000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 30 2670 3000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 30 2670 3000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 30 2670 3000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 30 2595 2700 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 30 2595 2700 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 30 2595 2700 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 25 2285 4000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 30 2595 2700 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 25 2285 4000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 25 2285 4000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 25 2285 4000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 25 2225 3000 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 25 2225 3000 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 25 2225 3000 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 25 2225 3000 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 25 2160 2700 95 60 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 25 2160 2700 95 38 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 25 2160 2700 95 24 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
product-img Tenace - Quadran Square 1120 105L x 105W x 165H 25 2160 2700 95 15 IP20 Diffused Lens/Softening Lens/Honeycomb Non Dim/Triac Dim/Analog Dim/DALI Dim/DALI Tunable/RF Tuneable Download Download Download Download
